40mm To 80mm Sleeve
- Available in 2 sizes to suit either Panel doors 20mm-40mm thick or Midrails 40mm-80mm thick - Suits a range of door thicknesses
- Fully suited aluminium flap and UV-safe black ABS frame - Quality and durability you can see and feel
- Anti-snap flap opens to 180° with fully sprung return - Easier to operate no broken flaps even with the Sunday papers
- 10" wide aperture - Meets Royal Mail standards will easily take A4 size post
- Secure through fixing ensures letterplate can only be removed from the inside of the house - Prevents burglars gaining access to the cylinder internally
- Can be through fixed or face fixed - Flexible according to fabricator preference
- Optional restricted opening with the addition of a PAS24 Letterplate Restrictor - Possible to restrict the opening angle or lock the flap shut
- Supplied with 70mm and 45mm screws - Everything needed for installation on a variety of door thicknesses
- Technical Specification
- Designed for PVC-U Composite and Timber doors
- Conforms to the requirement of BS EN 13724: 2002
- All finishes salt spray tested to 480 hours (BS EN 1670: Class 5)
- Flap cycle tested to 20000 cycles
- Includes 2 x M5 x 50mm machine screws 2 x M5 x 70mm machine screws and 2 screw guides
